160HP TD Farm Tractor
  • 160HP TD Farm Tractor160HP TD Farm Tractor

160HP TD Farm Tractor

GLORY is the China factory of The 160HP TD Farm Tractor with attachments. Equipped with five workshops and state-of-the-art processing and assembly lines, GLORY is a provider of comprehensive agricultural tractor solutions. GLORY also supply spare parts and attachments supports.

The 160HP TD Farm Tractor is a new 4wd agricultural model launched by Glory Tractor Factory. This 160HP TD Farm Tractor integrates state-of-the-art technologies and offers customizable configurations adapted to various terrains and climatic conditions, ensuring comprehensive fulfillment of operational requirements. Whether for dry fields or paddy fields, mountainous regions or plains, this 160HP TD Farm Tractor delivers optimal performance as your ideal agricultural machinery solution.


Product Advantage

1.Engine: Weichai, Huafeng, Laidong, Changchai, Yunnei and other well-known brands.

High horse power, low fuel consumption, reliable performance ,long lasting durability ,comprehensive after sale services.

2.Axle: Patented axle.

Made of high -strength steel, enhanced chassis with strong load bearing capacity, key components adopted imported bearings, which operate smoothly and reliably,adjustable suspension system to enhance driving comfort.

Chassis

3.Independently assemble the chassis to control the quality of the main parts.

4.Cab: Electrophoretic paint

Rustproof, sturdy and durable.

8+2, 8+8, 12+8, 12+12 are available.

5.Radiator: Large capacity radiator with high heat dissipation efficiency.

6.Tank: Made of high-quality materials, leak proof, large capacity, extending battery life.


Product Parameters

160HP TD Farm Tractor
Product model GL1604-TD
Overall dimensions (mm) 4920×2210×3030
Wheelbase (mm) 2550
Minimum usable mass (kg) 5120
Minimum ground clearance (mm) 490
Engine emissions National Second Engine
Engine brand LaiDong
Engine type Inline 4 cylinder
Engine calibration power (KW) 117.6
Engine calibration speed (r/min) 2200
Clutch type Double acting clutch, dry clutch
Number of gears in the gearbox 16+8
Axle TD
Tire specifications 14.9-28/18.4-38
Power output speed (r/min) 760/850
Hydraulic lifting system type Strong pressure dual oil cylinder
Maximum lifting force (KN) ≥28.22
Traction force (KN) ≥37.63
GL904-TD3S
Product model GL904
Overall dimensions (mm) 4030×1750×2700
Wheelbase (mm) 2050
Minimum usable mass (kg) 4412(safety rack)/4712(cab)
Minimum ground clearance (mm) 380
Engine emissions National Second Engine
Engine brand Huafeng4105T
Engine type Inline 4 cylinder
Engine calibration power (KW) 66.2
Engine calibration speed (r/min) 2200
Clutch type 12 inch Double acting clutch
Number of gears in the gearbox 12+12
Axle TD3S
Tire specifications 12.4-24/16.9-34
Power output speed (r/min) 760/850
Hydraulic lifting system type Strong pressure dual oil cylinder
Maximum lifting force (KN) ≥15.9
Traction force (KN) ≥21.17


160hp Td Farm Tractor160hp Td Farm Tractor



Hot Tags: High-power farm tractor, Chinese machinery exporter, 160HP TD Farm Tractor, Agricultural equipment supplier, GLORY OEM service
